The Spectra family of visual and audible signals are optimised solutions for all general applications: traffic management, access control, status indication and process monitoring safety warning. Environments include manufacturing, warehousing, aviation hangars, perimeters and tunnels.
NOTE: This product is now end of life and will be discontinued at the end of 2020.
| Datasheet | Datasheet.pdf |
| Installation Manual | B450TDB_D126-00-201-IS_Iss_B.pdf |
| Russian EAC Declaration of Conformity | D-GB.GA05.B.12595-20-24.03.2025.pdf |
| Russian Maritime register | 19.00193.278.pdf |
| Declaration of Conformity | DC-026_Issue_D_Spectra.pdf |
| 2D drawing (PDF) | SK0016_Issue_B.pdf |
| 2D drawing (DWG) | SK0016_Issue_B.dwg |
| Assembly drawing | SK0053_Issue_A.pdf |
| Bracket Accessory | SK0039_Issue_A_B450-Bracket.pdf |
| 3D drawing (STEP) | SK0016_Issue_A.STEP |
| Hi-res product image 1 (TIFF) | 2-11-040_B450TDB-A.tif |
| Hi-res product image 2 (TIFF) | 2-11-040_B450TDB-G.tif |
| Hi-res product image 3 (TIFF) | 2-11-040_B450TDB_ASSY.tif |
| Lo-res product image 1 (JPG) | 2-11-040_B450TDB-A.jpg |
| Lo-res product image 2 (JPG) | 2-11-040_B450TDB-G.jpg |
| Lo-res product image 3 (JPG) | 2-11-040_B450TDB_ASSY.jpg |
| Light source: | Dual Filament Lamp E14 |
| Light output: | 2 × 15W |
| Function: | Permanent |
| L.E.D. colours: | Amber, Blue, Clear, Green, Red & Yellow |
| Effective Intensity cd: | 24 cd* (peak/effective intensity) |
| Lens type: | Prismatic |
| Mounting: | Surface mount (Wall mount bracket available) |
| Entries: | 1 × 5-7mm push through grommet 2 x M20 cable entry |
| Dimensions: | ø140 x 177mm |
| Ingress protection: | IP65 |
| Housing material: | High impact UL94 V0 (f1) PC |
| Terminals: | 0.5 to 2.5mm² |
| Operating temp: | -25 to +50°C [-13° to +122°F] |
| Storage temp: | -40 to +70°C [-40 to +158°F] |
| Relative humidity: | 90% at 20°C [68°F] |
| *Candela measurements representative of performance with clear lens at optimum voltage. | |
| Version: | Part code: |
|---|---|
| 12-250V | B450TDB250B/[x] |
| [x] = Lens colour: | A: Amber B: Blue C: Clear G: Green R: Red Y: Yellow |
| Note: Filament lamps not included. Must be ordered separately | |
| Mounting brackets: | Description: |
|---|---|
| MB-B450T-S | Mounting bracket kit for a single B450 type unit. |
| MB-B450T-M | Mounting bracket kit for linked multiple B450 type units. |
| Version: | Wattage: | Type: | Part code: |
|---|---|---|---|
| 12V dc | 15W | E14 | BB261215E |
| 24V dc | 15W | E14 | BB263015E |
| 48V dc | 15W | E14 | BB264815E |
| 115V ac | 15W | E14 | BB2613015E |
| 230V ac | 15W | E14 | BB2623515E |
| Note: Filament lamps ordered separately. | |||
